Hammer Head Mill

Time:2024-07-18   Nums:4135

QQ图片20220908141051_副本.png        QQ图片20220908150106.png


Hammer pulverizer(Hammerhead Mill) is mainly suitable for crushing and processing of low hardness materials such as chemical industry, dyes, auxiliaries, feed, food, medicine, wood chips, chemical fiber and non-metallic minerals. Its fineness is adjusted between 20-120 mesh. It has the advantages of high yield, fine particle size, low noise, low energy consumption, simple maintenance, easy installation and so on. It is especially suitable for crushing and processing of low hardness materials such as non-oil, low viscosity, heat sensitivity, fiber (e.g. Dendrobium, pepper, ginger, cassava tablets, peanut soybean, octagonal, cinnamon, sugar, salt crystal, Chinese herbal medicine, miscellaneous grain, tea, pearl, chemical coating) and so on.

Characteristics and structural principles

The hammer pulverizer uses the high speed relative motion of the movable tooth disc and the fixed tooth disc to comminute the comminuted object through the comprehensive action of tooth impact, friction and material impact. Hammer type vertical mill has simple structure, strong, smooth operation and good crushing effect. The crushed material can be discharged directly from the main grinding chamber, and the particle size can be obtained by replacing the mesh screen with different aperture. In addition, the hammer type universal mill is A3 carbon steel. All the inner walls of the casing are machined to smooth the surface, which changes the roughness and powder accumulation of the inner walls of the previous models, and makes the production of drugs, food and chemical industry more in line with the national standards and meet the GMP requirements.

US$27215.00

Yiphee Electric Furnace Co.,Ltd specializes in producing induction furnace & Hammer Head Mill.Tel(WhatsApp):+86-13450756789, yiphee@yiphee.cn
